Description
Unboxing & Physical Snapshot
- Brand & Model: Honeywell RANGE2000, smart rangeable process transmitter
- Physical Dimensions: 5.4 in W × 5.1 in H × 7.2 in D
- Estimated Shipping Weight: 3.1 lb (packaged with shock-resistant foam and rigid export carton)
- What’s in the Box: Transmitter assembly, LCD local display, threaded process connection, factory calibration certificate; impulse piping and mounting bracket sold separately.
Product Introduction (Structure A: Environmental hook)
This Honeywell RANGE2000 smart transmitter operates in petrochemical, power and pulp & paper field locations, where wide process fluctuations, temperature cycling and corrosive ambient air degrade fixed-range transmitters. It delivers high turndown rangeability for pressure, differential pressure or liquid level measurement, converting sensed process variables to 4–20mA analog signal plus HART digital communications for DCS integration.
Onboard continuous sensor diagnostics detect overrange, sensor drift and loop wiring faults before measurement loss occurs. (Unflagged transmitter drift is a common nonconformity found during plant safety and metrology audits.) The rugged die-cast aluminum housing isolates internal electronics from moisture, dust and vibration in outdoor and classified plant areas.
Core Technical Specifications
| Parameter | Value |
|---|---|
| Device Type | 2-wire smart rangeable field transmitter |
| Output Signal | 4–20mA analog + HART 7 digital protocol |
| Power Supply | 12–42 VDC loop powered |
| Rangeability (Turndown) | Up to 200:1 configurable range |
| Measured Variables | Gauge pressure, absolute pressure, differential pressure, liquid level |
| Local Interface | LCD display, push-button local configuration |
| Operating Ambient Temp | -40 °C to +85 °C |
| Process Media Temp | -50 °C to +120 °C |
| Storage Temperature | -40 °C to +85 °C |
| Enclosure Rating | IP67, NEMA 4X |
| Construction | Die-cast aluminum housing, stainless steel sensor wetted parts |
Global Compliance & Industry Certifications
- CE Mark
- UL/cUL Listed
- ATEX / IECEx intrinsically safe available for qualified lots
- SIL 2 capable (system-level assessment required)
- NAMUR NE 107 compliant diagnostic behavior
The UL/cUL certification verifies housing integrity and internal component spacing to prevent ignition risk in hazardous classified process areas. Verify specific lot certifications with OEM.
Long-Term Storage & Asset Preservation Guide
Store the RANGE2000 transmitter in factory sealed anti-corrosion packaging inside a dry, temperature-stable warehouse. Humidity exceeding 60% RH can cause oxidation of wetted sensing surfaces and degrade internal electronic circuits. Inspect stored spare transmitters every 24 months. Re-calibration is recommended for units stored beyond three years; long shelf storage may introduce minor zero shift affecting process measurement accuracy. Do not stack heavy instrument hardware on the transmitter housing. Impact can shift internal sensor alignment and create permanent zero offset before field commissioning.
Physical Installation Prerequisites
Maintain minimum 30 mm clearance around the transmitter housing for heat dissipation and access to local pushbuttons. Excess radiant heat from hot piping accelerates electronic aging and introduces measurement drift. Mount the unit on a sturdy 2-inch pipe bracket or flat panel. Use shielded twisted pair cable for the 4–20mA HART loop and connect transmitter housing to local protective earth. Isolate impulse lines to prevent trapped gas or liquid that causes noisy readings.
Buyer’s FAQ
Q: What HS tariff code applies to Honeywell RANGE2000 for cross-border shipments? A: Primary HS classification falls under 902620 for pressure/level measuring transmitters. Confirm classification with your customs broker before export filings, as rulings depend on supporting technical documentation.
Q: What country of origin is marked on Honeywell RANGE2000? A: Country of Origin is United States. This marking appears on the transmitter nameplate and must be reproduced on commercial invoices for cross-border compliance audits.
Q: Does RANGE2000 ship pre-calibrated? A: Yes, factory zero and span calibration is completed before shipment. Application-specific measurement range and HART tag parameters need configuration via HART communicator or DCS software after installation.
Q: Should I purchase all-risk shipping insurance for this spare RANGE2000 transmitter? A: Yes. Internal pressure sensing elements are sensitive to shock. Hidden sensor offset damage may only be identified after loop power-up and calibration check. All-risk insurance covers full replacement value for transit handling defects.
