Description
Product Overview
The GE Fanuc IC697CHS770E is a dual redundant rear mount rack chassis for the GE Series 90-70 PLC platform. The suffix “E” denotes the hardware revision of the IC697CHS770 base rack. This chassis is split into two independent 6-slot sub-systems plus dedicated power supply slots, enabling installation of two separate or redundant PLC control systems within a single rack housing. The integrated high-speed VME backplane supports all Series 90-70 CPU, discrete I/O, analog I/O, communication and specialty modules, as well as compatible IC687 VME modules. Designed for high-availability control applications such as power generation, oil & gas, and heavy industrial processes, this legacy rack is end-of-active production and widely stocked as critical maintenance spare for existing 90-70 installations.
Technical Specifications
| Parameter | Details |
|---|---|
| Part Number | IC697CHS770E |
| Manufacturer | GE Fanuc / Emerson |
| Product Category | Dual Redundant Rear Mount PLC Rack / Chassis |
| Platform | Series 90-70 PLC |
| Slot Layout | 2 independent systems; each with 1 power supply slot + 6 module slots |
| Total Slots | 2 power supply positions, 12 module backplane slots |
| Backplane | VME high-speed parallel bus, 0.8-inch module spacing |
| Mounting Style | Rear mount, fits 10-inch deep control enclosures, standard 19-inch rack width |
| Compatible Power Supplies | IC697 series plug-in AC/DC and DC power supply modules |
| Max 5V Backplane Current | 20A (100W power supply variant); 11A (55W); 18A (90W 24/48VDC) |
| Construction | Rugged aluminum chassis, industrial grade backplane PCB |
| Operating Temperature | 0°C ~ +60°C |
| Storage Temperature | -40°C ~ +85°C |
| Relative Humidity | 5% ~95% non-condensing |
| Dimensions | 483 mm (W) × 283 mm (H) × 190 mm (D) |
| Approximate Weight | 9.07 kg |
Compliance & Certifications
- CE mark compliant with EMC and Low Voltage Directive
- Designed per GE Fanuc Series 90-70 industrial control standards
- RoHS compliant
- Factory continuity, backplane bus and power distribution functional test before shipment
Storage & Installation Guidelines
Storage Requirements
- Store in dry temperature-controlled warehouse; recommended ambient 10°C ~30°C, RH <70% non-condensing
- Remain sealed inside original packaging before installation
- Protect from mechanical shock, continuous vibration, dust and corrosive vapors
- ESD wristband required when unpacking and handling backplane and modules
Installation Instructions
- Execute lock-out/tag-out and fully de-energize all rack power before rack or module replacement
- Wear ESD protective gear to prevent electrostatic damage to backplane and electronic modules
- Mount the IC697CHS770E chassis inside the control cabinet using mounting hardware
- Install power supply modules into the dedicated left-hand slots of each sub-system
- Insert CPU, I/O and communication modules into the 6-slot sections, aligning connectors with the VME backplane
- Wire rack AC/DC input power, field I/O cables and communication wiring per GE Series 90-70 drawings
- Restore power, verify backplane power and module LED status
- Download PLC logic, perform I/O checkout and redundant system failover test; commissioning must be completed by certified GE Fanuc PLC technicians
FAQ
Q: What system uses IC697CHS770E? A: It is a dual redundant rear mount rack chassis for GE Fanuc Series 90-70 large-scale PLC control systems.
Q: What does the suffix E mean? A: “E” indicates the hardware revision level of the IC697CHS770 rack chassis; revision matching is recommended for spare replacement.
Q: Can two separate PLC systems run inside this single rack? A: Yes, the rack is physically partitioned to support two independent PLC subsystems, commonly used for TMR or dual redundant control architectures.
Q: What types of modules fit in this chassis? A: All standard IC697 Series 90-70 CPU, I/O, communication modules and compatible IC687 VME modules.
Q: What warranty is available? A: Standard 12-month warranty applies for fully tested racks operated under rated normal operating service conditions.
