Description
Product Overview
Manufacturer: General Electric (N-Tron / Red Lion) Part Number: 336A4940DNP516TX, Series: 516TX This is an unmanaged 16-port industrial Ethernet switch widely used in GE Mark VI / Mark VIe gas turbine control systems for power generation. Built on rugged metal housing, it provides deterministic Ethernet networking for DCS, turbine controllers, SCADA and field I/O devices in power plant environments. It is a legacy spare part for turbine control network replacement.
Technical Specifications
| Item | Parameter |
|---|---|
| Port Quantity | 16 × RJ45 10/100BASE-TX |
| Switch Type | Unmanaged, plug-and-play |
| Switching Method | Store-and-forward |
| Auto Negotiation | 10/100 Mbps, full/half duplex auto sensing |
| Power Input | 12–24 VDC, dual redundant power terminals |
| Mounting | DIN rail or panel mount |
| Enclosure | Heavy-duty metal case, IP30 |
| Operating Temperature | -40°C ~ +75°C |
| Humidity | 5%–95% non-condensing |
| Compliance | IEEE 802.3, IEEE 802.3u, CE, UL, RoHS |
| Dimensions | 145 mm × 105 mm × 55 mm |
| Weight | ~650 g |
Key Features
- Unmanaged design, no software configuration required for fast commissioning
- Dual redundant DC power input, prevents single power failure outage
- Extended wide temperature rating for power plant cabinet harsh thermal conditions
- High EMC immunity to withstand electrical noise from turbine and high-voltage equipment
- Auto MDI/MDIX crossover on all ports; no special crossover cables needed
- Broadcast storm suppression to protect control network from packet flooding
- Compact DIN rail mounting, easy integration inside turbine control cabinets
- Shock and vibration resistant, suitable for gas turbine skid installations
Application Scenarios
- GE Mark VI / Mark VIe gas turbine control system network
- Power plant DCS and auxiliary SCADA communication
- Industrial control network for steam turbine, generator control panels
- Oil & gas compressor control systems
- Legacy power system retrofit and spare replacement
Installation & Maintenance Notes
- Mount on DIN rail inside EMC shielded control cabinet, keep away from high voltage cables.
- Use shielded CAT5e industrial Ethernet cable for all field connections.
- Connect both redundant 24VDC power supplies for maximum reliability.
- Verify cable termination and ground bonding before power-up.
- Periodically inspect for dust buildup, loose RJ45 connections and power terminal corrosion.
- This is legacy turbine networking hardware; confirm firmware and network topology compatibility before replacement.
FAQ
Q: Is 336A4940DNP516TX managed or unmanaged? A: It is an unmanaged switch, plug-and-play, no web interface or configuration needed.
Q: What is the primary application of this N-Tron 516TX variant? A: It is specially deployed within GE Mark VI and Mark VIe gas turbine control networks in power plants.
