Description
At-A-Glance Executive Brief
- Model: EMT40024X (EMT40000 series)
- Brand: EMTECH (EMPower, Denmark)
- Part Type: Marine AC/DC power supply + intelligent battery charger
- Lifecycle status: Critical marine automation spare; stocked for brownfield vessel retrofit, shipyard overhaul and onboard emergency power maintenance
- System compatibility: Marine 24V battery bank, ship control & safety automation panels; converts AC mains to regulated 27.6VDC, charges backup batteries and supplies continuous DC power for navigation, alarm, control and safety systems during mains loss
- Weight: ~1.2 kg
Technical Introduction
Failure of EMT40024X cuts off the primary 27.6VDC supply and stops battery charging. Onboard 24V backup battery will gradually deplete, causing loss of power to ship automation, alarm systems, safety interlocks and navigation auxiliary circuits once battery voltage drops below operating threshold. This creates vessel operational hazards during sea voyage, port operation or emergency blackout conditions.
EMTECH EMT40024X belongs to the EMT40000 series marine-grade combined power supply and battery charger, designed for shipboard harsh environments. It accepts 200–240VAC mains input and delivers regulated 27.6VDC output, rated 15A continuous, for charging 24V lead-acid battery banks while simultaneously powering marine control and safety loads. The charger automatically manages battery charging profiles, float and boost charging cycles to preserve battery health and extend service life. Built-in comprehensive protection includes overvoltage, overload, short-circuit and overtemperature shutdown. Front panel LED indicators show power status, charging activity and fault alarms. The unit features forced cooling fan, rugged metal enclosure and marine compliance certifications for installation inside vessel electrical cabinets. Widely deployed on cargo ships, offshore vessels and workboats to supply DC power for fire & gas detection, alarm panels, automation I/O and emergency shutdown systems. Marine electrical and vessel reliability teams stock EMT40024X to restore onboard backup charging and DC power during planned dry-dock overhaul or unexpected power unit faults.
- Best Suited For
- Marine vessel 24V battery backup systems, ship automation and safety panels
- AC to 27.6VDC conversion + intelligent battery charging for offshore / commercial marine applications
- Direct drop-in replacement for existing EMTECH EMT40024X EMT40000 series power charger hardware
Core Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | EMT40024X |
| Manufacturer | EMTECH (EMPower, Denmark) |
| Product Type | Marine AC/DC Power Supply & Battery Charger |
| Series | EMT40000 |
| AC Input | 200–240 VAC, ±10%, 45–65Hz |
| Input Current | 3A |
| DC Output | 27.6 VDC |
| Output Range | 26.00–31.00V adjustable |
| Max Output Current | 15A |
| Protection | Overvoltage, overload, short circuit, overtemperature |
| Cooling | Internal cooling fan |
| Mounting | Panel mount |
| Operating Temperature | -20℃ ~ +60℃ |
| Humidity | 5–95% RH non-condensing, marine environment rated |
| Weight | ~1.2 kg |
| Environmental Details | Please refer to the OEM datasheet for complete environmental tolerances and marine certifications. |
Field Engineer’s Tech Notes
- Confirm AC input rating, battery bank type, capacity and charging setpoints before replacement; incorrect voltage setting will damage 24V ship batteries.
- Isolate AC mains and lockout/tagout before removal; disconnect battery bank positive terminal to prevent short circuit hazards.
- Inspect AC input wiring, battery cables, fuse terminals and grounding connections; loose terminals and corrosion are the leading cause of overheating and intermittent charger faults on vessels.
- After installation, verify AC power startup, DC output voltage, battery charging current and LED status indication. Monitor float/boost charge cycle, test fault shutdown protection, confirm DC load supply stability before re-connecting critical ship safety loads.
- ESD protection required while handling internal PCB components.
- Periodically clean cooling fan and ventilation filters; salt fog, dust buildup and fan failure are common failure modes in marine environments.
Adaptive QA & Testing Protocol
Each EMT40024X marine charger is bench tested with programmable AC source and resistive DC load. We verify AC power startup, regulated 27.6VDC output, full 15A load test, battery charging simulation and adjustable voltage range. Overload, short-circuit and overtemperature protection functions are validated. Front panel LED status indicators, cooling fan operation and internal PCB are visually inspected for corrosion, salt contamination, scratches or thermal damage. Full test reports are available upon request.
Buyer’s FAQ
Q: What is EMTECH EMT40024X used for? A: It is a marine AC/DC power supply and intelligent battery charger, converting ship 200–240VAC to 27.6VDC to charge 24V battery banks and supply continuous DC power for vessel automation, safety and alarm systems.
Q: What warranty applies for refurbished and NSFP EMT40024X? A: Refurbished and NSFP units carry a 12-month hardware warranty. Coverage excludes saltwater corrosion, improper battery type matching, AC surge damage, fan clogging and incorrect voltage configuration.
Q: What lead time should I expect? A: Stocked units ship 3–7 business days. If inventory depleted, we source surplus EMTECH EMT40024X marine power chargers.
Q: Can EMT40024X run without battery connected? A: It can supply 27.6VDC to DC loads without battery, but the battery management and charging functions will not activate.
