Description
At-A-Glance Executive Brief
- Model: RDCU-12C, ABB order code 3AUA0000036521
- Brand: ABB
- Part Type: ACS800 series converter control unit
- Lifecycle status: OEM obsolescent, stocked for wind farm and industrial ACS800 brownfield assets
- System compatibility: ACS800-67 converters, fiber link to AINT interface boards
- Weight: 0.60 kg
Technical Introduction
This controller manages pulse generation, protection logic and field I/O for ACS800 power stacks. Loss of the RDCU-12C halts converter operation and blocks setpoint control from supervisory systems. This board processes analog and digital interlock signals, executes motor or grid-side modulation algorithms, and communicates with the power stage over fiber optics to isolate high-voltage noise from low-voltage control circuits. It includes onboard I/O terminals for external feedback, fault signaling and analog setpoints. Relay outputs trigger cabinet interlocks and alarm paths. Sites keep spare units to minimize forced outage duration while planning legacy drive system migration.
- Best Suited For
- ACS800-67 wind turbine converter cabinets
- Industrial ACS800 multi-module power conversion systems
- Direct drop-in replacement for existing RDCU-12C control hardware
Core Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | RDCU-12C / 3AUA0000036521 |
| Product Family | ABB |
| Auxiliary Supply | 24 VDC |
| Analog Inputs | 3 (1 × 0…±10V, 2 × 4…20mA) |
| Analog Outputs | 2 × 4…20mA |
| Digital Inputs | 7 galvanically isolated 24VDC |
| Relay Outputs | 3 changeover contacts rated 2A |
| Internal Reference | ±10V reference, +24V auxiliary output |
| Inter-board Link | Fiber optic to AINT power interface board |
| Weight | 0.60 kg |
| Environmental Details | Please refer to the OEM datasheet for complete environmental tolerances. |
Field Engineer’s Tech Notes
- Fiber optic transceivers are fragile. Dirt, scratches or bent fiber leads create intermittent link faults that appear randomly under thermal cycling. Clean fiber end faces and inspect transceiver ports before power-up.
- Parameter sets and application firmware are stored on this unit. A replacement board arrives blank. Upload the matching firmware and restore saved drive parameters before energizing the converter stack.
Adaptive QA & Testing Protocol
Each RDCU-12C receives 24VDC bench power. We validate all digital input channels and test each relay output for proper switching. 4–20mA and ±10V signals are injected to calibrate analog input span, while analog outputs are measured across full range. Fiber communication handshake is verified using a matching AINT test board. Front panel run and fault LED states are checked under normal and simulated fault conditions. Full test reports or bench test video clips are available upon request.
Buyer’s FAQ
Q: Is RDCU-12C identical to part code 3AUA0000036521? A: Yes. RDCU-12C is the hardware product designation, 3AUA0000036521 is ABB’s ordering reference number for this exact control unit.
Q: What warranty applies for refurbished and NSFP RDCU-12C? A: Refurbished and NSFP units carry a 12-month hardware warranty. Warranty does not cover fiber port damage, misloaded firmware, or improper commissioning settings.
Q: What lead time can I expect? A: Stocked units ship in 3–7 business days. If inventory runs low, lead time extends while we source available surplus control boards.
Q: Will the converter start immediately after swapping the RDCU-12C? A: No. The new unit holds no application firmware or drive parameters. Restore the backup parameter file and load the correct firmware revision before energizing.
