Description
Product Overview
The ABB 3HAC025054-001 is a servo drive unit for ABB IRC5 robot controller systems. It delivers precision motor control and torque regulation for robot joint axes, converting DC bus power into variable frequency AC power to drive the robot servo motors. This drive module executes closed-loop position and speed control, and feeds back encoder and motor health data to the main robot controller. It is widely fitted on ABB 6-axis industrial robots used for welding, material handling, assembly, painting and machining automation. This unit is a common critical spare for robot workshops and manufacturing production lines.
Technical Specifications
| Parameter | Details |
|---|---|
| Part Number | 3HAC025054-001 |
| Manufacturer | ABB |
| Product Category | IRC5 Robot Servo Drive |
| Robot Controller Platform | IRC5 |
| Function | Axis servo control, speed & torque regulation for robot joints |
| Power Interface | DC bus input, AC output to robot servo motors |
| Feedback | Motor encoder signal processing |
| Status Indicators | LED indicators for power, fault and operational status |
| Mounting | Rack mount inside IRC5 control cabinet |
| Diagnostics | Over-current, over-voltage, over-temperature, short-circuit and encoder fault detection |
| Operating Temperature | 0°C ~ +55°C |
| Storage Temperature | -40°C ~ +85°C |
| Relative Humidity | 5% ~ 95% non-condensing |
| Approximate Weight | 3.2 kg |
Compliance & Certifications
- CE mark for EMC and Low Voltage Directive
- RoHS compliant
- Factory full power-on test, servo loop and communication verification before shipment
Storage & Installation Guidelines
Storage Requirements
- Store in dry temperature-controlled warehouse; recommended ambient 10°C ~30°C, RH <70% non-condensing
- Remain sealed inside original anti-static packaging before installation
- Protect from mechanical shock, continuous vibration, dust and corrosive vapors
- ESD wristband required when unpacking and handling PCB assemblies
Installation Instructions
- Execute lock-out/tag-out and fully cut off main power of IRC5 robot cabinet before replacement
- Wear ESD protective gear to prevent electrostatic circuit damage
- Remove cabinet cover, discharge DC bus capacitors completely
- Unplug power cables, encoder cables and backplane connectors of old servo drive
- Install new 3HAC025054-001 module into the rack and secure fasteners
- Reconnect DC bus, motor power and encoder wiring
- Restore cabinet power, run robot system startup and axis calibration via RobotStudio
- Perform jog test of each axis and validate fault alarms; commissioning must be completed by certified ABB robot technicians
FAQ
Q: What robot controller uses 3HAC025054-001? A: It is a servo drive for ABB IRC5 robot controller platform.
Q: What is the main function of this servo drive? A: It controls robot joint servo motors, regulating speed, torque and position for robot movement.
Q: Is capacitor discharge required before replacing the servo drive? A: Yes, DC bus capacitors hold high residual voltage. Full discharge is mandatory to avoid electric shock hazard.
Q: What software is used for robot commissioning? A: ABB RobotStudio for configuration, axis calibration and robot program management.
Q: What warranty is available? A: Standard 12-month warranty applies for fully tested servo drives operated under rated normal operating service conditions.
